Appendix D Parameters for Data Monitoring and Logging
154 PM135 Powermeter Series
Appendix D Parameters for Data
Monitoring and Logging
The following table lists parameters measured by the meter that are
available for monitoring through communications and for recording to a
data log file. The left column shows data abbreviations used in PAS.
Parameter groups are highlighted in bold.
Table 25: Data Monitoring and Logging Parameters
Designation
Description
NONE
None (stub, read as zero)
DIGITAL INPUTS
Digital Inputs
DI1:16
Digital Inputs Status DI1:DI12
RELAYS
Relays
RO1:16
Relay Status RO1:RO4
COUNTERS
Pulse Counters
COUNTER 1
Counter #1
COUNTER 2
Counter #2
COUNTER 3
Counter #3
COUNTER 4
Counter #4
RT PHASE
1-Cycle Phase Values
V1
V1/V12 Voltage
1
V2
V2/V23 Voltage
1
V3
V3/V31 Voltage
1
I1
I1 Current
I2
I2 Current
I3
I3 Current
kW L1
kW L1
kW L2
kW L2
kW L3
kW L3
kvar L1
kvar L1
kvar L2
kvar L2
kvar L3
kvar L3
kVA L1
kVA L1
kVA L2
kVA L2
kVA L3
kVA L3
PF L1
Power factor L1
PF L2
Power factor L2
PF L3
Power factor L3
V1 THD
V1/V12 Voltage THD
1
V2 THD
V2/V23 Voltage THD
1
V3 THD
V3/V31 Voltage THD
1
I1 THD
I1 Current THD
I2 THD
I2 Current THD
I3 THD
I3 Current THD
I1 KF
I1 K-Factor
I2 KF
I2 K-Factor
I3 KF
I3 K-Factor
I1 TDD
I1 Current TDD
I2 TDD
I2 Current TDD
