Appendix C Setpoint Triggers and Actions
PM135 Powermeter Series 153
Display Code
Designation
Description
Time and Date Parameters
Day of Week
DAY OF WEEK
Day of week
Year
YEAR
Year
Monh
MONTH
Month
Day of Month
DAY OF MONTH
Day of month
Hours
HOURS
Hours
Minutes
MINUTES
Minutes
Seconds
SECONDS
Seconds
Minute Interval
MINUTE INTERVAL
Minute interval: 1-5, 10, 15, 20, 30, 60 min
1
In 4LN3, 3LN3 and 3BLN3 wiring modes, the voltages will be line-to-neutral; for
any other wiring mode, they will be line-to-line voltages.
Table 24: Setpoint Actions
Display Code
Designation
Description
None
NONE
None (no action)
Relay 1 ON
OPERATE RELAY #1
Operate relay RO1
Relay 2 ON
OPERATE RELAY #2
Operate relay RO2
Relay 3 ON
OPERATE RELAY #3
Operate relay RO3
Relay 4 ON
OPERATE RELAY #4
Operate relay RO4
Relay 1 OFF
RELEASE RELAY #1
Release latched relay RO1
Relay 2 OFF
RELEASE RELAY #2
Release latched relay RO2
Relay 3 OFF
RELEASE RELAY #3
Release latched relay RO3
Relay 4 OFF
RELEASE RELAY #4
Release latched relay RO4
Increment counter 1
INC CNT #1
Increment counter #1
Increment counter 2
INC CNT #2
Increment counter #2
Increment counter 3
INC CNT #3
Increment counter #3
Increment counter 4
INC CNT #4
Increment counter #4
Time counter 1
TIME CNT #1
Count operation time using counter #1
Time counter 2
TIME CNT #2
Count operation time using counter #2
Time counter 3
TIME CNT #3
Count operation time using counter #3
Time counter 4
TIME CNT #4
Count operation time using counter #4
Notification
NOTIFICATION
Send a notification message
Data Log 1
DATA LOG #1
Record data to Data Log #1
