Chapter 5 Configuring the PM135 Configuring Communications
PM135 Powermeter Series 71
Chapter 5 Configuring the PM135
This chapter describes how to configure different options in your meter
from the front panel display or via PAS.
5.1 Configuring Communications
Setting Up Serial Communication Ports
Using the Front Display
Select COM1 Setup or COM2 Setup from the Device Setup menu. See
Viewing and Changing Setup Options in Chapter 3 for information on
configuring parameters via the front display.
Device Setup
Reset
Real Time Clock
Display Setup
Basic Setup
Device Options
COM1 Setup
COM2 Setup
See below for available communication options.
Using PAS
Select Communications Setup from the Meter Setup menu, and then
click on the Serial Ports Setup tab. In the Port box, select the desired
device port.
