Satec PM172EH series User Manual

Chapter 4 Setup Menus 33
Table 4-6 Setpoint Setup Options (middle window)
Code Option Description
LGC.1 - LGC.4 Logical operator
(OR/AND) for the
trigger
Connects the trigger condition to previous
setpoint conditions using specified logical
operator
trG.1 - trG.4 Trigger parameter The measurement parameter or signal to be
monitored by the setpoint.
On.1 - On.4 Operate limit for the
trigger
The threshold at which the setpoint
becomes operative.
OFF.1 - OFF.4 Release limit for the
trigger
The threshold at which the setpoint is
released (becomes inoperative).
Act.1 - Act.4 Setpoint action The action performed when the setpoint is
operative.
On d Operate delay The time delay (seconds) before operation
when the operate condition is fulfilled.
OFF d Release delay The time delay (seconds) before release
when the release condition is fulfilled.
Table 4-7 Setpoint Triggers (lower window, when middle window is
trG)
Code Parameter Unit Range
1
nonE Setpoint disabled
2
Status Inputs
4
St1.On Status input #1 ON
St2.On Status input #2 ON
St1.OFF Status input #1 OFF
St2.OFF Status input #2 OFF
Pulse Inputs
4
PlS.In.1 Pulse input #1
PlS.In.2 Pulse input #2
Counters
4
Cnt.1 High counter #1 0 to 999999
Cnt.2 High counter #2 0 to 999999
Cnt.3 High counter #3 0 to 999999
Cnt.4 High counter #4 0 to 999999
Relay Status
4
rL1.On Relay #1 ON
rL2.On Relay #2 ON
rL1.OFF Relay #1 OFF
rL2.OFF Relay #2 OFF
Voltage disturbance
4
U.diSt Voltage disturbance
5
% 1 to 100
Phase Reversal
4
POS.Ph.r Positive phase rotation reversal c
NEG.Ph.r Negative phase rotation reversal c
