34 Chapter 4 Setup Menus
Code Parameter Unit Range
1
Real-time Values per Phase
rt Hi.C1 High current L1 A 0 to Imax
rt Hi.C2 High current L2 A 0 to Imax
rt Hi.C3 High current L3 A 0 to Imax
rt Lo.C1 Low current L1 A 0 to Imax
rt Lo.C2 Low current L2 A 0 to Imax
rt Lo.C3 Low current L3 A 0 to Imax
Real-time Values on any Phase
rt Hi. U High voltage
6
V/kV 0 to Vmax
rt Lo. U Low voltage
6
V/kV 0 to Vmax
rt Hi. C High current A 0 to Imax
rt Lo. C Low current A 0 to Imax
rt thd.U High voltage THD % 0 to 999.9
rt thd.C High current THD % 0 to 999.9
rt HFc.C High K-factor % 1.0 to 999.9
rt tdd.C High current TDD % 0 to 100.0
Real-time Auxiliary Measurements
rt Hi.Fr High frequency Hz 0 to 100.00
3
rt Lo.Fr Low frequency Hz 0 to 100.00
3
Average Values per Phase
Ar Hi.C1 High current L1 A 0 to Imax
Ar Hi.C2 High current L2 A 0 to Imax
Ar Hi.C3 High current L3 A 0 to Imax
Ar Lo.C1 Low current L1 A 0 to Imax
Ar Lo.C2 Low current L2 A 0 to Imax
Ar Lo.C3 Low current L3 A 0 to Imax
Average Values on any Phase
Ar Hi. U High voltage
6
V/kV 0 to Vmax
Ar Lo. U Low voltage
6
V/kV 0 to Vmax
Ar Hi. C High current A 0 to Imax
Ar Lo. C Low current A 0 to Imax
Average Total Values
Ar Hi.P.i High total kW import (positive) kW/MW 0 to Pmax
Ar Hi.P.E High total kW export (negative) kW/MW 0 to Pmax
Ar Hi.q.i High total kvar import (positive) kvar/Mvar 0 to Pmax
Ar Hi.q.E High total kvar export (negative) kvar/Mvar 0 to Pmax
Ar Hi. S High total kVA kVA/MVA 0 to Pmax
Ar PF.LG Low total PF Lag 0 to 1.000
3
Ar PF.Ld Low total PF Lead 0 to 1.000
3
Average Auxiliary Measurements
Ar neU.C High neutral current A 0 to Imax
Ar Hi.Fr High frequency Hz 0 to 100.00
Ar Lo.Fr Low frequency Hz 0 to 100.00
Present Demands
Hi d.U1 High volt demand L1
6
V/kV 0 to Vmax
Hi d.U2 High volt demand L2
6
V/kV 0 to Vmax
Hi d.U3 High volt demand L3
6
V/kV 0 to Vmax
Hi d.C1 High ampere demand L1 A 0 to Imax
To Next Page
