Chapter 4 Setup Menus 35
Code Parameter Unit Range
1
Hi d.C2 High ampere demand L2 A 0 to Imax
Hi d.C3 High ampere demand L3 A 0 to Imax
Hi d.P.i High block interval kW import demand kW/MW 0 to Pmax
Hi d.P.E High block interval kW export demand kW/MW 0 to Pmax
Hi d.q.i High block interval kvar import demand kvar/Mvar 0 to Pmax
Hi d.q.E High block interval kvar export demand kvar/Mvar 0 to Pmax
Hi d.S High block interval kVA demand kVA/MVA 0 to Pmax
Hi Sd.P.i High sliding window kW import demand kW/MW 0 to Pmax
Hi Sd.P.E High sliding window kW export demand kW/MW 0 to Pmax
Hi Sd.q.i High sliding window kvar import demand kvar/Mvar 0 to Pmax
Hi Sd.q.E High sliding window kvar export demand kvar/Mvar 0 to Pmax
Hi Sd.S High sliding window kVA demand kVA/MVA 0 to Pmax
Hi Ad.P.i High accumulated kW import demand kW/MW 0 to Pmax
Hi Ad.P.E High accumulated kW export demand kW/MW 0 to Pmax
Hi Ad.q.i High accumulated kvar import demand kvar/Mvar 0 to Pmax
Hi Ad.q.E High accumulated kvar export demand kvar/Mvar 0 to Pmax
Hi Ad.S High accumulated kVA demand kVA/MVA 0 to Pmax
Hi Pd.P.i High predicted sliding window kW import
demand
kW/MW 0 to Pmax
Hi Pd.P.E High predicted sliding window kW export
demand
kW/MW 0 to Pmax
Hi Pd.q.i High predicted sliding window kvar import
demand
kvar/Mvar 0 to Pmax
Hi Pd.q.E High predicted sliding window kvar export
demand
kvar/Mvar 0 to Pmax
Hi Pd.S High predicted sliding window kVA demand kVA/MVA 0 to Pmax
Internal Events
4
PlS.Ac.i kWh import pulse
PlS.Ac.E kWh export pulse
PlS.rE.i kvarh import pulse
PlS.rE.E kvarh export pulse
PlS.rE.t kvarh total (absolute) pulse
PlS.AP.t kVAh total pulse
PlS.P.dn Start power demand interval
PlS.S.dn Start sliding window demand interval
PlS.A.dn Start volt/ampere demand interval
PlS.trF Start new tariff interval
Timers
4
t-r.1 Timer #1 sec 0 to 9999
t-r.2 Timer #2 sec 0 to 9999
TOU Parameters
4
trF Active tariff trF.1- trF.16
PrF Active profile PrF.1- PrF.16
Time/Date Parameters
4
U.dAY Day of week
Sun, Πon,
tuE, Ued, thu,
Fri, Sat
YEAr Year 0-99
