36 Chapter 4 Setup Menus
Code Parameter Unit Range
1
Πon
Month 1-12
Π.dAY
Day of month 1-31
hour Hour 0-23
Πin
Minutes 0-59
SEC Seconds 0-59
Event Flags
4
FG1.On Event flag #1 ON
FG2.On Event flag #2 ON
FG3.On Event flag #3 ON
FG4.On Event flag #4 ON
FG5.On Event flag #5 ON
FG6.On Event flag #6 ON
FG7.On Event flag #7 ON
FG8.On Event flag #8 ON
FG1.OFF Event flag #1 OFF
FG2.OFF Event flag #2 OFF
FG3.OFF Event flag #3 OFF
FG4.OFF Event flag #4 OFF
FG5.OFF Event flag #5 OFF
FG6.OFF Event flag #6 OFF
FG7.OFF Event flag #7 OFF
FG8.OFF Event flag #8 OFF
Setpoint Status
4
SP1.On Setpoint #1 ON
SP2.On Setpoint #2 ON
SP3.On Setpoint #3 ON
SP4.On Setpoint #4 ON
SP5.On Setpoint #5 ON
SP6.On Setpoint #6 ON
SP7.On Setpoint #7 ON
SP8.On Setpoint #8 ON
SP9.On Setpoint #9 ON
SP10.On Setpoint #10 ON
SP11.On Setpoint #11 ON
SP12.On Setpoint #12 ON
SP13.On Setpoint #13 ON
SP14.On Setpoint #14 ON
SP15.On Setpoint #15 ON
SP16.On Setpoint #16 ON
1
For parameter limits, see notes to Table 4-4.
2
The setpoint is operated when the actual phase sequence does not match the
indicated normal phase rotation.
3
The actual frequency range is 45.00 to 65.00 Hz.
4
For this trigger, release limit is not used.
5
Operate limit for the voltage disturbance trigger specifies the voltage deviation
allowed in percentage of the nominal secondary voltage. The tested voltage refers
to line-to-line voltage in 3OP2 and 3OP3 wiring modes, and to line-to-neutral
