Chapter 5 Data Display
53
6 1 Ph.L1
5
Label
6 2 PF Power factor L1 4
6 3 kW kW L1 4 kW/MW
7 1 kVA kVA L1 4 kVA/MVA
7 2 Ph.L1
5
Label
7 3 kvar kvar L1 4 kvar/Mvar
8 1 Ph.L2
5
Label
8 2 PF Power factor L2 4
8 3 kW kW L2 4 kW/MW
9 1 kVA kVA L2 4 kVA/MVA
9 2 Ph.L2
5
Label
9 3 kvar kvar L2 4 kvar/Mvar
10 1 Ph.L3
5
Label
10 2 PF Power factor L3 4
10 3 kW kW L3 4 kW/MW
11 1 kVA kVA L3 4 kVA/MVA
11 2 Ph.L3
5
Label
11 3 kvar kvar L3 4 kvar/Mvar
12 1 H01
4
(Fundamental) Label
12 2 PF H01 total power factor 4
12 3 kW H01 total kW 4 kW/MW
13 1 H1.L1
4,5
(Fundamental) Label
13 2 PF H01 power factor L1 4
13 3 kW H01 kW L1 4 kW/MW
14 1 H1.L2
4,5
(Fundamental) Label
14 2 PF H01 power factor L2 4
14 3 kW H01 kW L2 4 kW/MW
15 1 H1.L3
4,5
(Fundamental) Label
15 2 PF H01 power factor L3 4
15 3 kW H01 kW L3 4 kW/MW
MIN/MAX
Min/Max Measurements
3 Lo Label
1 1
V
1/V1-2 Minimum voltage L1/L12
7
4 V/kV
1 2
V
2/V2-3 Minimum voltage L2/L23
7
4 V/kV
1 3
V
3/V3-1 Minimum voltage L3/L31
7
4 V/kV
2 1 A1 Minimum current L1 4 A
2 2 A2 Minimum current L2 4 A
2 3 A3 Minimum current L3 4 A
3 1 kVA Minimum total kVA 4 kVA/MVA
3 2 PF Minimum total power factor 4
3 3 kW Minimum total kW 4 kW/MW
