Chapter 5 Data Display
55
Total Harmonics
THD/HD%
1 1
V
1/V1-2 Voltage THD L1/L12 3 %
1 2
V
2/V2-3 Voltage THD L2/L23 3 %
1 3
V
3/V3-1 thd Voltage THD L3 3 %
2 1 A1 Current THD L1 3 %
2 2 A2 Current THD L2 3 %
2 3 A3 thd Current THD L3 3 %
3 1 A1 Current TDD L1 3 %
3 2 A2 Current TDD L2 3 %
3 3 A3 tdd Current TDD L3 3 %
4 1 A1 Current K-Factor L1 3
4 2 A2 Current K-Factor L2 3
4 3 A3 HF Current K-Factor L3 3
Individual Voltage Harmonics
THD/HD%
1-40 1
V
1/V1-2 Voltage HD% L1/L12 3 %
1-40 2
V
2/V2-3 Voltage HD% L2/L23 3 %
1-40 3
V
3/V3-1 02H Voltage HD% L3 3 %
Individual Current Harmonics
THD/HD%
1-40 1 A1 Current HD% L1 3 %
1-40 2 A2 Current HD% L2 3 %
1-40 3 A3 02H Current HD% L3 3 %
Total Harmonic Power
10
POWER/
ENERGY
1 1 kVA Total harmonic kVA 4 kVA/MVA
1 3 kW Total harmonic kW 4 kW/MW
Total Harmonic Energy
10
POWER/
ENERGY
1 1 MWh Ac.En. Label
1 2 IP. Label
1 3 Harmonic MWh import 6 MWh
2 1 MWh Ac.En. Label
2 2 EP. Label
2 3 Harmonic MWh export 6 MWh
3 1 MVAh AP.En. Label
3 3 Harmonic MVAh 6 MVAh
