Appendix D Event and Data Logging 79
The data recorder can record up to 16 data parameters per record in each
of 8 data log files. The list of parameters is configured individually for
each data log file.
Before configuring data log parameters in your device, you should
allocate memory for the data log and specify how many parameters each
record will contain. Parameters that are not included into the record will
be designated as not available.
To configure the data log parameters, select Memory/Log from the Meter
Setup menu, click on the Data Recorder tab, and then select a data log
you want to configure.
To specify parameters for the data log:
1. Click on the “Group” box for the first parameter and select
a data group that contains the desired parameter.
2. Click on the “Parameter” box for the first parameter and
select a parameter from the list.
3. Select the other parameters in the same manner. For
your convenience, when you open the “Group” box for
the next parameter, PAS highlights the same group as in
your previous selection. If you select this group again,
PAS will automatically update the “Parameter” box with
the next parameter in the group.
Data logs #1 and #2 are preset at the factory for periodic recording of the
standard power quantities. Their default data log configuration is shown in
the following table.
Data Log #1
No. Parameter No. Parameter
1 V1 9 Total kVA
2 V2 10 Total PF
3 V3 11 V1 THD
4 I1 12 V2 THD
5 I2 13 V3 THD
6 I3 14 I1 THD
7 Total kW 15 I2 THD
8 Total kvar 16 I3 THD
Data Log #2
No. Parameter No. Parameter
1 V1 Demand 9 kVA sliding demand
2 V2 Demand 10 kWh Import
3 V3 Demand 11 kWh Export
4 I1 Demand 12 kvarh Import
5 I2 Demand 13 kvarh Export
6 I3 Demand 14 In
7 kW import sliding demand 15 Frequency
8 kvar import sliding demand 16 Digital input #1
