SATO CG408 User Manual

Section 2: Installation
CG4 Series Operator Manual Page 2-13
2.5 CONNECTIONS (cont’d)
2.5.5 Turning On the Power
Press the POWER on the operation panel of the unit.
The ERROR indicator displays red, then after a single beep
sound, the ON LINE (POWER) indicator displays green.
2.5.6 Turning Off the Power
When you have completed the printing job, turn the printer
off.
Be sure to confirm that the printer is in the offline status.
Press and hold the POWER button until the ERROR
indicator displays red and then turns off.
If there is any printed paper remaining in the printer,
cut it off.
Warning
Do not operate the power switch or insert/remove the
power cable while your hands are wet. Doing so may
cause an electric shock.
ERROR
Beep
sound
ON LINE
(POWER)
ERROR

SATO CG408 Specifications

General

Resolution	203 dpi
Max Print Width	104 mm
Print Method	Thermal Transfer
Max Print Speed	4 inches/sec
Media Roll Diameter	127 mm (5 inches)
Memory	4 MB Flash
Interface	USB, Serial, Ethernet
Media Sensor	Reflective and Transmissive
Media Thickness	0.06 mm - 0.19 mm
Ribbon Length	100 m (328 ft)
Label Thickness Range	0.06 mm - 0.19 mm
