SATO CG408 User Manual

Section 3: Operation and Configuration
Page 3-6 CG4 Series Operator Manual
3.3 USER TEST PRINT MODE (cont’d)
Second print-out (Protocol code setting values)
Third print-out (Interface)
USB and RS-232C interface on board
No. Print Item
1STX
2ETX
3 ESC
4ENQ
5CAN
6 NULL
7OFFLINE
8 AUTO ONLINE
9 ZERO SLASH Zero slash
10 EURO Euro code
No. Print Item Contents of the print data
1 Selected Interface In-use interface USB / RS-232C / Keypad /
Scanner
2 Interface 1 Interface 1 USB
3 Buffer Type Buffer type Multi
4 Protocol Protocol Driver
5 Serial No. Serial No. Serial No./ None
6 Interface 2 Interface 2 RS-232C
Communication parameters (19200.8.N.1)
Baud rate (bps)
9600, 19200, 384000
Data length (bit)
8, 7
Parity
N, O, E
Stop bit (bit)
1 2
7 Buffer Type Buffer type 1 item / Multi
8Protocol Protocol ER/RS
XON/XOF
Driver
Status3

SATO CG408 Specifications

General

Resolution	203 dpi
Max Print Width	104 mm
Print Method	Thermal Transfer
Max Print Speed	4 inches/sec
Media Roll Diameter	127 mm (5 inches)
Memory	4 MB Flash
Interface	USB, Serial, Ethernet
Media Sensor	Reflective and Transmissive
Media Thickness	0.06 mm - 0.19 mm
Ribbon Length	100 m (328 ft)
Label Thickness Range	0.06 mm - 0.19 mm
