SATO CL408 - Rotate, Moving Base Reference Point

Rotate, Moving Base Reference Point
Command Structure Normal Direction: <ESC>N
Rotated Direction: <ESC>R
Example: See above
Placement: Preceding any printed data to be rotated
Default: <ESC>N
Command Function The <ESC>R command rotates the printing of all subsequent images
in a print job by 90° counterclockwise each time it is used. It also
moves the base reference point to a different corner of the print area.
The <ESC>N command returns to the original base reference point
and returns printing to the normal orientation.
Input to Printer
<ESC>A
<ESC>N<ESC>H0100<ESC>V0010<ESC>MNORMAL DIRECTION
<ESC>R<ESC>H0100<ESC>V0100<ESC>MONE
<ESC>R<ESC>H0100<ESC>V0100<ESC >MTWO
<ESC>R<ESC>H0100<ESC>V0100<ESC>MTHREE
<ESC>R<ESC>H0100<ESC>V0100<ESC>MFOUR
<ESC>Q1<ESC>Z
Printer Output
Special Notes
Section 4. Programming Reference
Page 4-709001035 Rev. ESATOCL SeriesPrinters
