SATO CL408e - Page 176

Page 9-22
Section 9. Optional Accessories
SATO CL408e/CL412e Service Manual
PN 9001078
Rev. A
PCMCIA Memory Expansion Installation
INSURE STANDOFFS
ARE BETWEEN MAIN
PCB AND MEMORY
CARD
MEMORY PCB
BOARD
MAIN PCB
BOARD
SECURE MEMORY
BOARD WITH (2)
SCREWS PREVIOUSLY
REMOVED
SECURE FROM UNDERSIDE OF
MAIN PCB BOARD WITH (2)
SCREWS AND WASHERS
PREVIOUSLY REMOVED.
Fig. 9-37
