SawStop 10” Professional Cabinet Saw 41
Preparing Your Saw
Green
Green
White
White
T1 T2
L1 L2
A2
COIL
THERMAL CIRCUIT
BREAKER
MOTOR
CABLE
POWER
CABLE
CONTACTOR BOX
SWITCHBOX
CABLE
A1
COIL
CONTACTOR
White
Black
Black
Red
Black
GROUND
Fig. 55
230V PCS-WA-025 Contactor Box
Wiring Diagram:
Preparing Your Saw for Use
