1-8
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Setting up communications for displaying a website
Quickstart
1
1.7.2 USBportasserviceport
This port is generally used as a service port with the WVGA standard MB panels. It
is mainly used to load new rmware into the device.
The USB port complies with the USB 1.1 specication. Highest speed: 12 Mbit/s.
1.7.3
Accessing the web editor on the Micro Browser Panel PCD7.D4xx
Detailed documentation can be downloaded from our website. See manual 26-838
Manual Web-Editor. To access the programming of the MB panel, you must note
some special features:
■ When creating a new project and receive no help from the assistant, you must
congure the project as follows:
● Use of the virtual keyboard with WVGA MB panels, see "4.5 Keyboard" on
page 4-11
● If you want to use the le Background.teq or foreground.teq, you should rst
create these les. The reason for this is… These les are rst positioned on
each page be-fore any objects or texts and elds appear
● Once the project is ready for download, enter the relevant HTML le name and
create a build project. Now execute a web server build in the Saia PG5 project
manager so that all les access the PCD. If you only want to access the PCD
with the MB panel PCD7.D4xx and not a PC browser, you can reduce the data
quantity by deleting the .jar les as they are already available on the panel.
