SBC PCD7.D450WTP Series User Manual

2-1
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Technical data of the WVGA MicroBrowser panel
Technical data
2
2 Technical data for the two panel types
2.1 Technical data of the WVGA MicroBrowser panel
HMI - Line Base Base
Type PCD7.D450WTPF,
PCD7.D450WTPZ11
PCD7.D470WTPF,
PCD7.D470WTPZ11
Display
Display size 5" TFT 7" TFT
Resolution (pixels) WVGA 800 × 480 WVGA 800 × 480
Colours 65,536 65,536
Adjustable contrast Yes
Background lighting LED (dimmable in 20 stages)
Touch Screen Resistive 4-wire
CPU
Processor Coldre CF5373L / 240 MHz
Memoryforlocallesystem 128 MB
Real-time clock (RTC) Yes with Super-Cap
Interfaces
Ethernet 1× Ethernet Interface RJ 45 / http direct
USB 12M 1× Client
Serial ---
Operating system Saia PCD
®
COSinus
Browser Saia PCD
®
Micro Browser
Server FTP server
Software tools
Graphic editor Web Editor 8 and 5
Use of PG5 resources Yes
Technical data
Power supply 18…32 VDC
Current draw 350 mA 400 mA
Housing protection type
(front)
IP65
Operating temperature 0 … 50 °C –20 … 70 °C
Storage temperature –20 … 70 °C
(non-condensing)
–25 … 70 °C
(non-condensing)
Dimensions (W×H×D ) [mm] 166 × 127 × 45.6 204 × 157 × 49
Cut-out (W×H) [mm] 157 × 117 189 × 142
Display size (W×H) [mm] 109.4 × 66.2
Display size (W×H) [mm]
up to HW: <F
152 × 91.44
Display size (W×H) [mm]
starting with HW: ≥F
154.08 × 85.92
