8 General recommendations for the Web Editor 5
8.1 Inthe"Projectcongurations"
Î Select a standard typeface to be used for most projects!
8.2 In the Web Editor project (general information)
■ It is recommended to use text elds, which exceed the size displayed in the Edi-
tor by up to 20%. You can nd details in section "6.4 Typefaces supported by MB
panel PCD7.D4xx" on page 6-3.
■ IMasterSaia5_xx_xx.jar is not required in order to display a website on the MB
panel.
■ The .tcr le is the only le which needs to be integrated into the Web Server
project (.wsp). All other project les can be copied into the ash memory (PLC or
local server of the MB panel) under INFLASH/webpages/.
■ Add Unicode fonts Consult: http://www.sbc-support.com Product Info
HMI Web-Panel PCD7.D4xxx Additional information for Sales Compa-
nies (restricted area)
■ If the correct typeface is not in the list please contact PCD Support in Murten,
where we would be happy to help.
■ The container oset name (container name) must not contain any underscores or
@ signs (i.e., not: PDP-ADDRESS+@COFF_containername@, PDP-FORMAT).
■ Consider that the sux for container oset is d for a decimal and k for the format
HH:MM
■ Use "Online trends macros" with the right timestamp: The time server must be
activated in the Setup menu.
■ For information on calculating the amount of memory required, see "6.7 List of
message box messages" on page 6-16 and "8.5.3 Decompression of Gif les:
analysis/calculation" on page 8-4.
■ Viewing angle: the surface (front panel of the unit) projects a few millimetres over
the display. You should therefore leave a frame of 4-5 pixels free (black) around
the view.
■ PPOs: Number of objects per page: tested with 1024 objects (1024 objects
with 3 ags per object = 3072 ags)
■ PPOs: Number of registers per page: tested with 475 registers
■ Maximum number of objects (painters) per page is 512 objects
■ Project conguration Scaleable HTML: dene HTMLs, where the HMI is
adjusted during the run time by a dened factor. For example, scale your HMI to
200%, without having to modify the TEQ views. MicroBrowser adapts the TEQ
views during run time if you enter your new ‘scaleable' HTML le instead of the
standard HTML le.
Examples: Factor 2.000000 means 200% of 640 × 480, i.e. 1280 × 960;
a factor < 1 (< 100%) is not suitable for applications with the MB panel.
