4-6
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
System
Structure and description of the setup menu
4
4.3 System
4.3.1 Info
System info, such as Firmware Version, Booter Version, etc.
Î Firmware Version
Firmware version currently installed on the panel
Î Booter Version
Booter version currently installed on the panel
Î CPLD Version
Version of the Programmable Logik Chip
Î Expansion
Indicates if an expansion is available, ASN and rmware version of the expansion
Î Video Cache Permanent
Info: permanent video cache used
Î Erasable Video Cache
Info: cache is used for images. Dependent upon the size and number of gif les
in the cache
4.3.2 Production data
Display of the most important production data, such as serial number and ASN.
Î ASN
SBC product number (order number)
Î Serial number
Serial number of the device
Î MAC Address
MAC address of the device
Î HW Version
Hardware version of the device
Î Production Date
Month in which the device was produced
Î Display Type
Type of display (internal designation)
Î HW LCD Rotation
Rotation of the display
