4-9
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
System
Structure and description of the setup menu
4
Î Timeout
Timeout for which the FTP data channel is not connected to any communication
Î Maximum open connections
Maximum number of open data connections to the FTP server
Î Removestandarduser
The user “root” is activated or deactivated with the password “rootpasswd”
4.3.5 Log
Clicking the button scrolls further through the list. This allows you to check, for ex-
ample, if typefaces are found. The last screen gives info on error messages.
Access to log.txt via FTP: uBT_FS/LOG.TXT
4.3.6 Firmware download
The panel is set in bootloader mode to download new rmware
Î Download via USB
Î Download via Ethernet
4.3.7 Restart
Restarts the system.
