SBC PCD7.D450WTP Series User Manual

6-10
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Internal special functions
Handling: precautionary measures
7
6.6 Internal special functions 6.6.1 ContainervariableforWVGAMBpanel
The conguration le UBTERMINAL.TXT is not accessible via the FTP connection, because this le is located in the (write- protected) subdirectory/PLC_SYS/CONFIG/. Containers allow the application to exchange data with the rmware. All container variables havethe prex "uBT_". Pay attention to upper/lower case!!!
Congle entry
Container (source HN 10.03.10)
Type Default Minvalue
Min length
MaxvalueMax length
Description
R/W uBT_AlarmFrequency Decimal value string 1000 125 8000 Frequency setting for the acoustic alarm (Hz)
(based on 125,250,500,1000,2000,4000,8000) Set before using the alarm. A change in frequency while the alarm is sounding will take effect only when the next alarm is called.
No uBT_AlarmStart Decimal value string 0 0 30000 = 30 sec. Dene a value to start or stop the pulsed, acoustic alarm.
The acoustic alarm can be started by setting an interval time (0 - 30,000 mSec) for the pulsed signal. A 50% pulse/pause ratio is used, i.e. the pulse time is equal to the pause time. Changes made while the alarm is already sounding are ignored. At a setting of 0, however, the alarm is immediately deactivated. The alarm is stopped immediately by touching the screen.
R/W uBT_AlarmVolume Decimal value string 10 0 20: 100% Volume of the acoustic alarm (0 - 20).
As pulse width modulation is used, this setting has an effect on the perceived pitch of the alarm. Set before using the alarm! A change in volume while the alarm is sounding will take effect only when the next alarm is called.
R/W uBT_AutoRepeat Boolean value string 0 0 1 Via the Soft Input Panel SIP (on-screen keyboard), use:
SIP keyboard: AutoRepeat on (1), off (0 )
No uBT_BackLight Boolean value string 1 0 1
Read/Write 1, 0  Remote control for backlight OFF. The backlight is switched OFF if the value was previously ‘1’. When the screen is touched, the backlight is switched back on again immediately. Read/Write 0, 1  Remote control for backlight ON. The backlight is switched ON if the value was previously ‘0’. There may be a delay when switching off. Remote control via PPO  Container coupling, only. Use on painters for buttons and edit elds is not supported.
