6-11
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Internal special functions
Handling: precautionary measures
7
Congle
entry
Container
(source HN 10.03.10)
Type Default Minvalue
Min length
MaxvalueMax
length
Description
No uBT_BackLightOn Boolean value string 1 0 1 Direct operation of the backlight by making an entry in this container
(1: On, 0 : Off).
Status of the backlight is set to read back. Container is set by activating the backlight by
touching the screen and reset after switch off with uBT_BackLightTimeout.
Areas of application: remote monitoring and remote control via PPO Container
coupling, local user control right on the terminal via the painter for buttons (mouse button
pressed, mouse button released) and locally via the painter for edit elds in the web
project.
R/W uBT_BackLightTimeout Decimal value string 15 0 5000 Time (min) until backlight switches off. When the screen is touched or switched on by the
container, the backlight is switched on and the countdown begins.
If value=0: no time-delayed monitoring of the backlight. In this case, the backlight remains
permanently switched on.
Read only uBT_BooterVersion ANSI text string Current version
string
0 8 Firmware booter version
String read, only
Read only uBT_CongType ANSI text string Curr. cong. type 0 24 Conguration type
String read, only
R/W uBT_DefaultGateway String IP address 0x00 00 00 00 * * Read/write IP address of the gateway on the subnet being used (forced position, over-
writes default).
* Setting is 0: forced position deactivated.
If the setting=0: depending upon the router you are using, it may not be possible to
reach external addresses outside of the subnet. If this setting is changes, a restart is
necessary. This will mean FTP connections are lost.
No uBT_DispResolution ANSI text string <Screen width>
<Screen height>
<Color depth>
0 16 Info on resolution
String read, only
Yes uBT_DisplayRotation UTF8 1) !!!
Text string
0°
(0x30 C2 B0)
0° 270° Rotation 0°,90°,180°,270°
If a change is made, a restart will be necessary.
This will mean FTP connections are lost.
!!!! 1) Direct display of UTF8 may not be supported by the FTP client.
The screen is displayed rotated, meaning that it may not be fully visible, even with
automatic scaling.
When the upscaling function is activated, the scaling of the non-rotating screen
remains consistent with the rotating screen. Calibration of the rotating screen is the
same as on the non-rotating screen. In order to alter the calibration, please return
to the non-rotating screen.
