6-12
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Internal special functions
Handling: precautionary measures
7
Congle
entry
Container
(source HN 10.03.10)
Type Default Minvalue
Min length
MaxvalueMax
length
Description
R/W uBT_EnableCache Boolean value string 1 (activated) 0 1 The le cache is used (1), 0 no le cache for all visualisation les, which are not images.
Files are cached for the rst time as soon as they are used.
Regardless of the local le settings, les are searched for rst in the cache memory.
The cache memory is wiped upon startup and URL jumps.
Image les are decompressed and cached in a separate, always activated video cache.
This video cache is wiped upon startup, URL jumps and whenever too much data has
been loaded. When this occurs, all necessary les are reloaded and decompressed.
R/W uBT_EnableSIP Boolean value string 1 (activated) 0 1
Read/write SIP Select the Soft Input Panel (virtual keyboard)
Write 0 SIP is deactivated. Virtual keyboards are deactivated
Write 1 SIP is activated. Virtual keyboards (alphapad.teq and keypad.teq) are acti-
vated.
No uBT_FlashStatus Decimal value string 0 0 255 INTFLASH
Status 20: Device present, no le system
Status 21: Device present, le system OK
Status 22: Device present, error during creation of le system
Status 23: Device present, creation of le system in progress
Status 24: Device present, compression of ash sector in progress
Status -1: Unknown error
R/W uBT_FocusBorderWidth Decimal value string 2 0 5 When the painter for edit elds and buttons is displayed, a rectangular focus frame
indicates that it is activated.
This setting is used for the line thickness (in pixels) of the focus frame: 1-5
0: Focus frame is switched off.
R/W uBT_InactivityPollTime ANSI text string 0 0 5 Setting for touchscreen / keyboard inactivity (1), switched off at 0.
To switch to a less frequent touchscreen/keyboard call.
No uBT_IntFlashStatus Decimal value string 0 0 255 Status of the internal ash memory
20: Device present, no le system
21: Device present, le system OK
22: Device present, error during creation of le system
23: Device present, creation of le system in progress
24: Device present, compression of ash sector in progress
-1: Unknown error
R/W uBT_IntroGraphicName ANSI text string SBCSU Grande.
gif
0 20 Intro graphic
R/W uBT_IntroGraphicXPos Decimal value string 100 0 639 Position of the intro graphic (horizontal position, from the left)
R/W uBT_IntroGraphicYPos Decimal value string 50 0 479 Position of the intro graphic (vertical position, from the top down)
R/W uBT_IntroText ANSI text string Welcome 0 32 Startup text
R/W uBT_IntroTextXPos Decimal value string 350 0 639 Position of the startup text (horizontal position, from the left)
R/W uBT_IntroTextYPos Decimal value string 300 0 479 Position of the startup text (vertical position, from the top down)
