6-13
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Internal special functions
Handling: precautionary measures
7
Congle
entry
Container
(source HN 10.03.10)
Type Default Minvalue
Min length
MaxvalueMax
length
Description
R/W uBT_TCPIPAddr String IP address 0xC0 A8 0C 5A:
192.168 12.90
* * Read/write the TCP/IP address of the terminal (own address) within the subnet being
used.
* If the setting is changed, a restart is required. This will mean FTP connections are lost.
No uBT_IsTSPresent Decimal value string Current value 0 255 Touchscreen was detected (1).
If the value is 0, calibration will be skipped during startup.
R/W uBT_LcdContrast Decimal value string 10 0 20: 100% Contrast and brightness setting for the backlight (0:20).
Increasing the value means greater brightness.
R/W uBT_LocalFileSearch Decimal list string Local before remote
(1)
0 2 Search mode for local le search
0: Do not search local les
1: Search local les before remote les
2: Search remote les before local les
No uBT_MACAddr ANSI text string 0 20 Own MAC address (read, only)
No uBT_MultiKeyValue ANSI text string 0 0 1 Container is not available
External SIP keyboard multikey display (1).
At 0: multikey combinations not activated
R/W uBT_S-BusAddr Decimal value string 10 0 253 Own S-Bus address
R/W uBT_ ScaleMode Decimal list string Auto (0) 0 2 Setting for upscaling mode
Auto (0): Smaller views are automatically adapted to the size of the terminal screen, one
view at a time. QVGA views are enlarged to the full screen size of VGA terminals (2x
horizontal and vertical zoom with pixel doubling).
VGA (1): Forced position for VGA without upscaling of smaller views. This is why upscal-
ing is switched off on VGA terminals. QVGA
(2): Force upscaling with pixel doubling on VGA terminals.
The setting takes effect on the next view jump, URL jump, or after a restart.
Read only uBT_SerialNumber Hex. or dec. 0 8 Serial number (read, only)
No uBT_Setup Text - - - Enter "show” (pay attention to upper/lowercase). A pop-up window opens on the terminal
containing the Setup menu.
R/W uBT_SubNetMask String IP address 0xFF FF FF 00 * * Read/write subnet mask of the subnet used by the terminal. *
If a change is made, a restart will be necessary.
This will mean FTP connections are lost.
Read only uBT_Version ANSI text string Current version
string
0 32 Firmware version
String read, only
R/W uBT_RtcDate ANSI text string The date is obtained from the real time clock on the MB panel. (Real Time Clock (RTC)
must be activated in the Setup menu)
R/W uBT_RtcTime ANSI text string The time is obtained from the real time clock on the MB panel. (Real Time Clock (RTC)
must be activated in the Setup menu)
*: In general, IPv4 private addresses are used. The default settings are:
- 1 x A class with subnet mask 10.x.x.x and mask 255.0.0.0 – sections can also be used.
- 16 x B class with subnet mask 172.16.x.x to 172.31.x.x and mask 255.255.0.0 – sections or combinations can also be used.
- Or 256 x C class with subnet mask 192.168.0.x to 192.168.255.x and mask 255.255.255.0 - combinations can also be used.
