INSTALLATION
MANUAL
© Scania CV AB 2018, Sweden
Components – Stage V
01:07 Issue 17 en-GB 13
IMPORTANT!
The differential pressure sensor must be slightly inclined when compared to the ver-
tical plane, so that condensation can run off it. Maximum installation angle is 30° rel-
ative to the vertical plane.
max 30°
0°
397 840
