Warnings and torque reduction for Stage IIIB/IV/Tier 4i/Tier 4f
01:07 Issue 17 en-GB 56
Reaction to fault in SCR system
Once the fault has been remedied and the engine control unit has received an indica-
tion that the SCR system is operating i.e. when the fault code has been acknowledged
in SDP3, torque returns to the normal level.
If a new fault occurs within 40 hours of operation since the first fault, the warning
lamp will come on. After 30 minutes of operation, the warning lamp will flash rap-
idly and torque will be reduced to 0% (low idling) within 30 minutes.
Time Warning lamp Torque reduction
1
1. Applies only to engines that are certified according to Tier 4.
Fault detected Constant light
After 30 minutes Flashes slowly (½ Hz) Torque is reduced by 1%
per minute to 70% of the
highest torque.
After 4 hours Flashes rapidly (2 Hz) Torque is reduced to 0%
(low idling) within 2-10
minutes.
340 423
Symbol for fault in the exhaust gas aftertreatment system, ISO 7000 - 2596.

Scania DC16 Specifications

General

Engine Type	Diesel
Displacement	16.4 liters
Fuel Type	Diesel
Configuration	V8
Bore x Stroke	130 mm x 154 mm
Compression Ratio	17.3:1
Fuel System	Common rail
Aspiration	Turbocharged
Turbocharger	Yes
Aftertreatment	SCR
Cooling System	Liquid-cooled
Weight	Approximately 1350 kg (dry weight)
Power Output	up to 770 hp
