INSTALLATION
MANUAL
© Scania CV AB 2018, Sweden
Reductant tank
01:07 Issue 17 en-GB 41
Mounting
Attaching the 38 and 60 litre tanks
The reductant tanks with a capacity of 38 and 60 litres are fitted using six M14 studs.
The bracket is threaded so that screws without nuts can be used if the studs are re-
moved.
Bracket for the 38 and 60 litre reductant tanks.
340 437
10010020
250
340 438
