Reductant tank
01:07 Issue 17 en-GB 49
Available lengths of reductant hoses
You can order reductant hoses with the total length 2.5 m, 4 m, 5 m or 6.5 m. Below
you can see how much of the reductant hose length from the reductant pump is not
available for installation. The value is the longest measurement which is unavailable,
no matter whether it is a pressure hose or return hose.
12345
366 207
Hose length which is unavailable for installation, between the reductant pump and the marking.
1. 38 litre tank: 0.8 m.
2. 60 litre tank: 0.9 m.
3. 45 litre tank: 0.7 m.
4. 63 litre tank: 1.1 m.
5. 70 litre tank: 0.8 m.
