INSTALLATION
MANUAL
© Scania CV AB 2018, Sweden
Reductant tank
01:07 Issue 17 en-GB 38
Dimensions for 45 litre reductant tank Dimensions for 63 litre reductant tank
Dimensions for 70 litre reductant tank
353 437
510 415
701
340 427
668
414
704,6
349 418
575
470
585
