Conditions of Use and Installation
Conditions of Use and Installation
Necessary preparatory work at the customers premises are to be arranged by the machine operator them-
selves. The work must be carried out by registered installers in compliance with general - including local - reg-
ulations. Schaerer Customer Service may only connect the machine to existing prepared connection points.
Schaerer Customer Service is neither authorised nor responsible for carrying out any work prior to con-
nection!
Mains voltage tolerance 220 V - 230 V + 6 % - 10 %, mains outage < 50 ms no interruption
of function
Water supply
(optional constant water connec-
tion)
3/8 inch flexihose connector with mains tap and filter on customer
supply side, water temperature max. 35 °C.
min. 0,2 MPa flow pressure at 2 l/min., 0,6 MPa
Water quality For drinking water over 5° dCH (carbonate hardness) a Schaerer
anti-scale filter should be included.
Drain outlet
(optional)
Flexihose to DN 19, min. gradient 2 cm/m
Ambient temperature + 5°C to max. + 35°C
(Do not expose the coffee machine to frost).
Maximum humidity
Protection
80 % relative humidity without condensation, no water spray, do
not use unit outdoors! IP X0
Inbuilt clearances For operating, service and safety reasons the machine should be
installed with clearance of not less than 50 mm at the back and
sides from the building or non-Schaerer components.
A clear height of 100 mm from the top of the supporting surface
should be ensured. Recommended height of the working surface
is a minimum of 850 mm from floor level.
If the machine connections are to be routed down through the
counter, remember also to allow space for the connections. These
may restrict the available space below the machine.
Anti-scale filter installed dimensi-
ons (03.9314.0001)
490 mm (height) x 118,8 mm (diameter)
plus space requirement for the connection tubes
*Theexistingelectricitysupplymustconformtothecurrentlyvalidnationalrules(forGermany,VDE0100).ToimprovesafetythecoffeemachineshouldbettedwithanFI30mA
earthleakagecurrentcircuitbreakertoEN61008standards.Aplugtopwallsocketshouldbettednearthemachine.Ifthemainsconnectionleadofthiscoffeemachineisdamagedit
mustbereplacedbySchaererCustomerServicesorasimilarlyqualiedperson.Ifthecoffeemachineispermanentlyconnectedtothemainsthenanall-poledisconnectingseparator
(mainsswitch)toEN60947standardswithaminimum3mmcontactgapmustbeincluded.Forexibleconnectionaseparatorswitchisrecommended.Mainscablemustnotcome
intocontactwithhotsurfaces.Mainsswitchandplugtoparepartofthecustomer‘son-siteinstallation.Themachinemaynothaveaxedpermanentmainsconnectionifinstalledon
any mobile furniture item.
