www.schaerer.com Product description
BA SCV_EN
V05 | 04.2013
12
Technical data
We reserve the right to make technical changes.
* For special equipment, see serial plate. The values specified here apply to the basic equip-
ment.
** Depending on machine configuration and model.
*** The sound pressure level balance A Lpa (slow) and Lpa (impulse) at the operators' work-
place is less than 70 dB (A) in each operating mode.
Serial plate
The serial plate label is found behind the drip tray on the left side and behind the left machine
cover plate.
► In case of a technical problem or warranty claim, state the serial number specified on the
serial plate.
Rated wattage*: 2000 – 2200 W 10 – 16 A
Mains power supply*: 220 – 240 V CA 50/60 Hz
Operating temperature*: Steam boiler ** Hot water boiler **
Minimum (Tmin. ) 10°C 10°C
Maximum (Tmax. ) 192°C 192°C
Overpressure: Steam boiler ** Hot water boiler **
Working overpressure 2.5 bar 2.5 bar
Permissible working overpressure (pmax. ) 12 bar 12 bar
Test overpressure 24 bar 24 bar
Filling quantities
Drinking water tank 4.5 l
Coffee bean hopper ca. 1100 each g
Grounds container 40 – 45 coffee grounds cakes
Powder system Choco Choco 1x1000 g / Twin Choco 2 x 500 g
External dimensions:
Width 329 mm
Height 836 mm
Depth 583 mm
Empty weight: 36 kg
Continuous sound pressure level*** <70 dB (A)
Power cable length 1.0 m
Example of serial plate
