Spare parts
Contactors CP Series – Installation and Maintenance Instructions
10. Spare parts
Important!
Depending on the type of contactor, dif-
ferent types of spare parts must be used.
When ordering spare parts, always specify
the precise type and article number of the
contactor. You can nd this data on the
rating plate.
10.1 Pre-charging contactor (CPP)
Quantity Spare part, designation
1 CPP 24 V
1 CPP 36 V
1 CPP 48 V
1 CPP 60 V
1 CPP 72 V
1 CPP 84 V
1 CPP 96 V
1 CPP 110 V
10.2 High-voltage discharging contact
(CPD)
Qty Spare part, designation
1 CPD
10.3 Auxiliary switch assembly
Qty Spare part, designation
1 Auxiliary switch assembly 2x S826
1 Auxiliary switch assembly 2x S870 a1/b0
10.4 Arc chamber complete
Qty Spare part, designation
1 Size 1: 600A-4MW
Size 2+3: 1,200/2,000 A - 10MW
1 Size 1: 600A-2MW
Size 2+3: 1,200/2,000 A - 5MW
10.5 Main contacts
Qty Spare part, designation
1 NO/NC devices 600 A:
Set of main contacts
1 NO/NC devices 1,200 A:
Set of main contacts
1 NO/NC devices 2,000 A :
Set of main contacts
10.6 Contact bridge assembly
Consisting of spring sleeve, spring, spring support and
contact bridge, see also Fig. 32 and Fig. 33 on page 33
Qty Spare part, designation
1 NO devices 600 A:
Contact bridge assembly
1 NO devices 1,200 A:
Contact bridge assembly
1 NO devices 2,000 A:
Contact bridge assembly
1 NC devices 600 A:
Contact bridge assembly
1 NC devices 1,200 A:
Contact bridge assembly
1 NC devices 2,000 A :
Contact bridge assembly
10.7 Magnetic drive complete (without
main contacts)
Qty Spare part, designation
NO NC CO
1 Magnetic drive complete
24 V DC
M N B M N B N B
1 Magnetic drive complete
36 V DC ... 48 V DC
1 Magnetic drive complete
72 V DC ... 110 V DC
1 Magnetic drive complete
220 V DC / 230 V AC
M = monostable (on via supply voltage)
N = monostable (on via separate control input)
B = bi-stable
