Contactors CP Series – Installation and Maintenance Instructions
Introduction
4. Introduction
4.1 CP series – 1 and 2 pole bi-direc-
tional high-voltage contactors, dis-
connectors, changeover switches
for DC and AC
Modular and compact switchgear for modern power
converters
With the CP series Schaltbau is introducing once more
an innovative concept to the switchgear market. The
arc-handling is done exclusively by permanent-mag-
netic blowout. This patented technology ensures fully
bi-directional breaking capability and a more compact
design. By reducing dimensions and weight we save
you valuable space.
For the rst time the universal devices can be cong-
ured as NO/NC contactor, disconnector or changeover
switch. This enables us to react exibly to changing
customer requirements. The high switching function-
ality and reliability ensure practical and cost eective
operation.
The combination of innovative technology, compact
design and high versatility makes the CP-power contac-
tors particularly suitable for use in railway and indus-
trial applications.
Thanks to its unique modular design, the new product
family includes a variety of possible congurations ca-
tering to a wide range of applications.
4.2 Features
Innovative Design
X Available as NO/NC/CO contactor.
X DC bi-directional or AC up to 60 Hz max.
X Eective arc-handling – no critical currents and
low wear of main contact system thanks to perma-
nent-magnetic blowout
X High making capacity, also as disconnector and
changeover switch
X Low total cost of ownership, modular and compact
Main contact system
X Conventional thermal current: 600 A/ 1,200 A/
2,000 A
X Nominal voltage: 1.5 kV, 3 kV
X Double-break contacts
X 1 pole (NO/NC) and 2 pole (CO) versions
Easy maintenance:
X Toolless inspection of main contact tips (only ap-
plicable for NO/NC contactors with arc chamber)
X Toolless replacement of the arc chamber (only ap-
plicable for NO/NC contactors with arc chamber)
4.3 Applications
Main contactor, optional with pre-charging
contactor and high-voltage discharging contact for:
X Traction converters
X Inverters for auxiliary equipment
Switchgear for various mobile and stationary
applications
X Locomotives and multiple-unit trains
X Photovoltaic systems, wind turbines, cranes, weld-
ing systems, mining
Contactor for:
X Field circuits of motors
X Conventional resistor based traction units
X Activating the brake unit for DC drives
X Starter and compressor motors, solar cells
Switchgear for the conguration of electrical system
X Selection from among various energy sources
X Filter conguration for multisystem operations
X Connect/disconnect the DC link
4.4 Technical information and material
specication
For technical information, dimensions and material
specications, refer to our catalogue C40. The cata-
logue is available under:
https://www.schaltbau.com/en/media-library/
