Schindler 3100/3300/6300 J 43402603 / 01 105/269
Copyright © 2017 INVENTIO AG
0303
DOOR MAX LOCK TIME
A door was for a too long period of time in locked position. Note that monitoring
the time the door is in locked position prevents the motor from burning. Note
that this error might occur while the car is moving slowly (for example, during
learning travel or emergency power recall travel)
C1:Parameter 'max door lock time' is set wrong
A1:Check corresponding parameter (CF03 PA07)
0304
DOOR KSKB
The door wasn't able to close successfully due to an mechanical blockade.
This error occurs once if the door has tried to close for more than 50 times and
the closing got always aborted due to an activated door closing force limiter
(KSKB). The elevator gets blocked if this error appears too often within a
certain time period (typically 7 times in 3 hours = 350 attempts/3 h).
C1:Obstructions/barriers in the door zone or in the slit/gap
A1:Remove obstacle
C2:Door closing force limiter feedback signal KSKB is faulty
A2:Check contact KSKB for dirt or bad mechanical adjustment. Check
general wiring KSKB.
0312
DOOR CLOSED WITH WRONG COMMAND
*)
C1:(1) No DOOR_CMD = DOOR_CLOSE/ DOOR_LOCK given (2) Door is
not reversing (3) KET_S gets active (4) doorState=stopped=motor off
A1:
– mismatched KET_S and KET_O
– the direction of the motor is wrong
– the door is reversed just before reaching KET_S but the door reaches
this contact because of inertia
– the motor can be connected invert
0313
DOOR SHAFT ERROR
The subsystem door has received a door open command while the car is not
detected to be on floor. The command is rejected.
C1:Different causes
A1:Check elevator message log for previous reported messages in order
to identify the root cause of the problem.
C2:Failure at door zone detection of hoistway information system
A2:Check door zone detection of hoistway information system
(for example, PHSx, mechanical adjustment, defective sensor etc.)
0314
DOOR PRE-OPENING
There was an activation or deactivation failure of the door safety circuit bypass
device while the elevator was intended to perform a door pre-opening.
C1:Wiring of door safety circuit bypass device faulty
A1:Check general wiring of door safety circuit bypass device
C2:Door zone detection faulty
A2:Check door zone signals and sensors (for example, PHSx,
PHUETx).Check position of door unlocking zone indicators in hoistway
(for example, vanes on same level)
C3:Failure at door safety circuit (KTS, KTC) bypass device
A3:Replace PCB containing this bypass mechanism (for example, SUET)
Code Car Door Message
