Schindler 3300 - Machine and Brake Replacement Tests

Schindler 3100/3300/6300 J 43402603 / 01 176/269
Copyright © 2017 INVENTIO AG
4.10.2.4 Machine and Brake Replacement Tests
Verifying of the
Balancing Factor
8
On HMI, press "OK" and verify the acceptance criteria of the test as follows:
For elevator with
rated KG = 50 %:
– First test run:
– Test passed if the car stops below KNE (= KNE not triggered)
– Test failed if the car hits the KNE (= KNE triggered).
Repeat the test one more time.
–
Second test run:
– Test passed if the car stops below KNE (= KNE not triggered)
– Test failed if the car hits the KNE (= KNE triggered).
Replace the brake system within 4 weeks.
For elevator with
rated KG < 50 %:
– Test passed if:
– The car stops below the KSE-U magnet (= KSE-U magnet not
triggered).
– HMI shows [65/_1/__], indicating "Single brake test up successful".
–
Test failed if:
– The car stops above the KSE-U magnet (= KSE-U magnet triggered).
– HMI shows [65/_0/_5], indicating "Single brake test up failed".
If the test failed, replace the brake system within 4 weeks.
9 On HMI, press "ESC" to deactivate the test. HMI shows [__/__/65].
10 On HMI, deactivate the test mode as follows:
a)
Press "ESC". HMI shows [20/__/_1].
b)
Deactivate the test mode. HMI shows [20/__/_0].
c)
Press "OK". HMI shows [20/__/__].
d)
Press "ESC". HMI shows [- -/- -/- -].
The car performs a synchronization travel.
11 Repeat the whole test procedure with the second test connector TEST-MGB1.
12 In case of rated KG < 50 % only: If the dynamic single brake test upward
failed, make sure that the test load is available for the tests (with loaded car)
after replacement of the brake system.
No Step
1
Calculate the balancing factor, KG.
Balancing factor (KG) = 100 x
[counterweight mass (GG) - car mass (GK)]
load (GQ)
Trigger:
KG Balancing Factor [XX] = 50:
Tests after brake replacement can be performed with empty car
Perform 'Dynamic Full Brake Test Up' (Test 15)
Perform 'Dynamic Single Brake Test UP' (Test 65)
KG Balancing Factor [XX] = 40:
Test after brake replacement must be performed with 100 % and 125 % of GQ
Perform 'Dynamic Full Brake Test Down' (Test 14)
Perform 'Dynamic Single Brake Test Down' (Test 64)
