Schindler 3100/3300/6300 J 43402603 / 01 167/269
Copyright © 2017 INVENTIO AG
4.9.6 EN81-20/50 Door Bypassing Function
– The door bypassing function provides a means for maintenance person to make the
troubleshooting for car door or landing door safety contacts.
– Maintenance person can use the HMI function “Safety chain tap name display to
determine which safety contact is open, see info below.
– The maintenance person handles the doors (car door or landing door) bypass device
with a defined plug to move the car in recall or inspection mode to check for the
broken door safety contacts.
– The bypass connector is monitored by the controller and the elevator will be blocked
if a false plug has been detected by the controller.
8033
MAINS POWER OK
Mains power is correctly detected.
8034
CAR ALARM TEST FAILURE
Automated alarm test fails.
8035
CAR ALARM TEST OK
Automated alarm test passed.
8036
ELECTRICAL INDICATOR COP OK
Electrical indicators on COP are OK
8038
CAR DAILY TESTS NOT PERFORMED
This event is logged in case of none of the following tests has been performed
in the previous 24h:- COP indicator- LOP indicator- Alarm- Emergency car
light.
8039
CAR ROOF TEMPERATURE BROKEN MISSING
Temperature sensor provides abnormal values
The temperature is above 120° C
or the temperature is below -40° C
ID Possible Causes Actions to be taken
1
Temperature sensor broken Replace sensor
2 Temperature sensor missing Check cabling
Code Switch Controller Message
8099
SW OUT OF RAM
Controller has finished the RAM
Code Car Alarm Message
