Schindler 3100/3300/6300 J 43402603 / 01 203/269
Copyright © 2017 INVENTIO AG
Safety Switch Replacement [38608; 06.07.2011]
4.11.4.6 Reset
Reset After
Activation
When the overspeed governor has been triggered some steps should be followed.
For a non desired actuation of the overspeed governor for car/counterweight check that
no persons are inside the car. If someone is inside proceed, with the rescue operation as
described in the instruction manual of the installation. If there are no persons in the car:
– Move the car/counterweight upwards.
– Manually by means of releasing the brake and moving the hand-wheel of the
machine.
– Automatically, moving it with the main power of the machine.
– Release the pendulum.
– Raise the pendulum and disengage the pendulum nose from the pulley.
– Check the overspeed governor pulley turns freely.
– Release the safety switch.
– Reset the safety switch with the Electrical Remote Reset (ERR).
1 Precontact plate
2 Safety switch
3 Switch head
4Switch screws
