Schindler 3100/3300/6300 J 43402603 / 01 238/269
Copyright © 2017 INVENTIO AG
4.13.2 Safety Gear - RF0002
4.13.2.1 Overview Information
Component Title Safety gear
Type Captive roller RF0002
Description
Component Layout Guide rail blade thickness (mm): 10
Minimum height of rail blade (mm): 28
Range of
Application
Operation The safety gear is operated by a slack-rope tripping device.
Operating
Instructions
The operating instruction contains important advice for proper and safe installation,
commissioning, usage, and maintenance of the safety gear. Its observance will help to
avoid risks, to reduce repair cost and outage time, and to increase the reliability and the
operating life of the safety gear.
RF 0002
Instantaneous safety gear Type
Tripping Speed [m/s] Maximum Total Mass RF0002 [kg]
0.50 3264
0.60 3141
0.70 3006
0.80 2865
0.90 2720
1.00 2574
1.10 2431
1.20 2290
1.32 2130
1.65 1734
Parameter Value
Width of guide rail blade 10 mm
Max. mass of counterweight 2574 kg
Car speed 1.0 m/s
Max. rated counterweight speed 1.0 m/s
Max. counterweight tripping speed 1.62 m/s
