7 Abbreviations
7.1 Engineering
Abbreviation Description Unit
BFK
Width of guide rail head mm
GG Weight of counterweight frame + filling kg
GH Weight of traveling cables (half the cable length) kg
GK Actual car weight (sling + enclosure) kg
GKU GQ+GK+GU+GH (for a car) kg
GGU GG+GU+GH (for a counterweight) kg
GU Weight of all rope compensation elements kg
GQ Rated load kg
VCA1 Tripping speed of governor of car m/s
VCA2 Tripping speed of governor of counterweight m/s
VKN Rated speed of the car m/s
VKI Inspection speed m/s
s Running clearance mm
HQ Maximum travel height m
HFP Height of profile of guide rail mm
Abbreviation Description Unit
DZ
Governor rope diameter mm
FC Friction force of rope at speed governor N
FCU Tension force of governor rope at return pulley N
FLC Engaging force of safety gear at governor lever N
HQ Maximum travel height m
VCA (1/2) Tripping speed of governor (1 car, 2 counterweight) m/s
VCAG Max. possible tripping speed of governor in free fall m/s
VCK (1/2) Operating speed of governor contact (1 car, 2
counterweight)
m/s
VKN Rated speed of the car m/s
VKI Inspection speed m/s
Abbreviation Description Unit
BFK
Width of guide rail head mm
FC Friction force of rope at speed governor (in down/up
direction)
N
FLC Engagement force of safety gear at governor lever N
GG Weight of counterweight frame + filling kg
GGU GG+GU+ GH (for a counterweight) kg
