Schindler 3300 - Page 266

Schindler 3100/3300/6300 J 43402603 / 01 266/269
Copyright © 2017 INVENTIO AG
GH Weight of traveling cables (half the cable length) kg
GK Actual car weight (sling + enclosure) kg
GKU GQ+GK+GU+GH (for a car) kg
GQ Rated load kg
GU Weight of all rope compensation elements kg
HFP Height of profile of guide rail mm
Designation Description
SA
Safety component
GED Double acting progressive safety gear with eccenter
1 Size (1 or 2)
0 Version (0 or 5)
A Used guide rail type (A = cold drawn, B = machined)
S Used car type (S = centered, R = cantilever)
Abbreviation Description Unit Safety Gear Type
SA GED
10/15
SA GED
20
A
Width of safety gear [mm] 253 285
B Height of safety gear [mm] 125 146
C Depth of safety gear [mm] 112 122
D Distance to supporting bolt (height) [mm] 100 116
E Distance to supporting bolt (depth) [mm] 42 41
F Supporting bolt diameter [mm] 24 28
A Width of safety gear [mm] 253 285
Designation Description
HP
Buffer height
HPH Buffer stroke
VPAZ Maximum admissible speed of impact on buffer
VKNZ Maximum admissible rated speed
GPZ1 Minimum admissible mass for one buffer
GPZ2 Maximum admissible mass for one buffer
GP Weight of the buffer (without oil)
Abbreviation Description Unit
