Schindler 3100/3300/6300 J 43402603 / 01 251/269
Copyright © 2017 INVENTIO AG
[49422; 29.11.2013]
4.14.4.3 Maintenance Checks
Task List
Check the functioning and safety of every landing door lock:
– Check that the doors slide freely, without damages to the panels and with an
acceptable noise level when running
– Check that there is no overwear of the panel guide shoes
– Check the conditions of the lower and upper guides
– Check the gap between panels and between panels and side posts
– Check that the wire ropes and belts are not worn out
– Check the belt tension
– Check that the landing door emergency lock release operates properly
– Check that the door operator close limit switch operates properly
– Check that the re-opening device operates properly
– When necessary, grease with a lithium based grease which can be used with
temperatures between - 30° and + 120°
– Check the bottom track cleaning.
No Step
8 Remove the template. The adjustment is complete.
