Schindler 3100/3300/6300 J 43402603 / 01 237/269
Copyright © 2017 INVENTIO AG
4.13.1.4 Perodic Tests
Tension Pulley
Weight
Reduce the overspeed governor tension pulley weight by half:
– Before doing the safety gear test check, do a visual check under the car to make
sure that all the relevant components are in good condition.
– Enter the Acceptance Test Mode with the help of the HMI User Interface:
Press OK: [10/ /xy], Change to: [20/ /xy], Press OK: [20/ /0], Change to: [20/ /1],
Press OK.
– HMI display shows [20/ /xy]
– With the help of the UP/DOWN buttons choose "Safety Gear Test Empty Car"
(Test 75).
– HMI display shows [ / /75]
– Press OK to confirm your choice.
– HMI display shows [75/ / ]
– Press OK again to enter the test.
– HMI display shows [75/ / 1] "Test active" and the car moves to the highest floor.
– Connect the recall control and turn JRH to position "Recall".
– HMI display shows [75/ / 1]
– Press the DRH-D button on the recall control, keep it pressed and press at the same
time the OK button on the HMI User Interface.
– HMI display shows [75/ / 1]
– The elevator starts a trip downwards. "75" is blinking.
When the inspection speed is reached "75" is blinking together with "1" and the
buzzer beeps.
– HMI display shows [75/ / 1]
– When the buzzer beeps, press the DBV button (on SMICHMI/SMICFC) to engage
the safety gear.
– The car stops and an ACVF error is registered.
– HMI should show [75/ 1/ ] = Test successful.
– Indications: [75/ 1/ ] = Test successful, [75/ 0/ 1] ... [75/ 0/ 6] = Test not according
to the instruction, [75/ 0/ 7] = Test failed.
– Leave the Acceptance Test Mode: Press ESC until [20/ / 1] is displayed, Change to
[20/ / 0], Press OK, Press ESC.
– HMI display shows [ / /xy]
– Release the safety gear of the car with the help of the recall control. Check for
damages on the guide rails.
