Dynamic Full Brake
Test Up (Test 15)
Remark
Dynamic Single
Brake Test Upward
(Test 65)
Car load 0 % GQ
Travel speed 100 % VKN
Car travel direction UP
No Step
1 Active 'Test Mode'
– Press 'OK' [10/__/_0]
– Select
'Test mode' [20/__/__]
– Press
'OK' [20/__/_0]
– Activate
'Test mode' [20/__/_1]
–Press
'OK' [20/__/_1]
The car travels to the control cabinet floor and opens the door.
The door remains open
[__/__/--]
2 Select 'Full Brake Test Up'
– Select
"Start 'Full Brake Test Up" [__/__/15]
– Press
'OK' [15/__/_1]
The door closes
The car travels to the bottom floor
The door remains closed
"Test ready to run" [15/__/_2]
3 Start 'Full Brake Test Up'
– Press
'OK'
– The car starts a trip to the top floor
– HMI display shows a blinking "15"
[15/__/__]
– The car reaches rated speed
– HMI display shows a blinking "15"
[15/__/_1]
– The controller triggers an emergency stop below the KSE-U magnet.
Passed: The car has stopped below KSE-U and the HMI displays
‘Full Brake Test Up’ was successful
[15/_1/__].
Failed: The car has stopped above the KSE-U magnet and the HMI displays
'Full Brake Test Up failed’
[15/_0/_5]. The elevator must be put out of
service immediately until the brakes have been replaced and re-tested.
4 Deactivate 'Full Brake Test Up'
– Press ESC [__/__/15]
5 Deactivate 'Test Mode'
– Press ESC [20/__/_1]
– Change to
"Deactivate Test Mode"[20/__/_0]
–Press
’OK’ [20/__/__]
– Press
ESC
The elevator performs a synchronization trip.
Car load 0 % GQ
Travel speed 100 % VKN
Car travel direction UP
