Schindler 3100/3300/6300 J 43402603 / 01 154/269
Copyright © 2017 INVENTIO AG
3511
SAFETY CHAIN SIM DOORZONE CONTACT OVERBRIDGING
DEACTIVATION UNSUCCESSFUL
The cancellation of the overbridging of the door safety circuit contacts, allowing
to travel the car with opened doors (for example, used in fire operation Korea)
wasn't successful.
C1:Cancellation of door safety circuit overbridging failed
A1:Check errors 0340 for cause and actions
3512
SAFETY CHAIN SIM DOORZONE CONTACT UNEXPECTED
OVERBRIDGING *)
3513
SAFETY CHAIN ERROR NOT RECOVERABLE
The elevator wasn't able to recover from a opened safety circuit error (typ. after
20 repetitive door closing attempts). The elevator is blocked.
C1:Safety chain is open permanently
A1:Check where safety chain is open and why it does not close
3514
SAFETY CHAIN PIT ACTIVATION CHECK UNSUCCESSFUL
The periodic check if the overbridging of the safety circuit contacts in the pit is
running (for example, used in fire operation Korea) has failed.
C1:Overbridging relays defect
A1:Check function of relays RUESG, RUESG1 and RSG_A
C2:Wiring from/to overbridging relays bad
A2:Check wiring of relays RUESG, RUESG1 and RSG_A
C3:Fieldbus communication problem (please check previous errors in
error log)
A3:Check error 3603 for cause and actions
3515
SAFETY CHAIN PIT DEACTIVATION CHECK UNSUCCESSFUL
The periodic check if the cancellation of the overbridging of the safety circuit
contacts in the pit is running (for example, used in fire operation Korea) has
failed.
C1:Overbridging relays defect
A1:Check function of relays RUESG, RUESG1 and RSG_A
C2:Wiring from/to overbridging relays bad
A2:Check wiring of relays RUESG, RUESG1 and RSG_A
C3:Fieldbus communication problem (please check previous errors in
error log)
A3:Check error 3603 for cause and actions
3516
SAFETY CHAIN KNA ACTIVATION CHECK UNSUCCESSFUL
The periodic check if the overbridging of the safety circuit contact at the car
emergency exit is running (for example, used in fire operation Korea) has
failed.
C1:SIAP PCB defect (for example, relays simulating door zone
(PHS/PHS1) defect)
A1:Replace SIAP board
Code EEPROM Message
