Schindler 3100/3300/6300 J 43402603 / 01 182/269
Copyright © 2017 INVENTIO AG
Post Requisites
8 Acceptance Criteria
– Press ’OK’
Passed:
The car has stopped above KSE-D and the HMI displays
‘Dynamic Single Brake Test Down’ was successful
[64/_1/__].
Failed: The car has stopped above the KSE-D magnet and the HMI displays
‘Dynamic Single Brake Test Down’ failed
 [64/_0/_5]. The elevator can
remain in operation AND the replacement of brake system within next 4
weeks
.
9 Deactivate 'Single Brake Test Down'
– Press ESC  [__/__/64]
10 Deactivate 'Test Mode'
– Press ESC  [20/__/_1]
– Change to
"Deactivate Test Mode"[20/__/_0]
– Press
’OK’  [20/__/__]
– Press
ESC
The elevator performs a synchronization trip
11 Perform 2
nd
'Single Brake Test Down'
– Repeat this procedure for the second brake module with the "TEST-
MGB1"
connector
12 Unload the car
-
No Step
No Step
1
Remove labels "Out of service"
2 Perform a test ride over the whole travel distance
3 Record "Brake replaced and acceptance test fulfilled" in the maintenance log
