No Step
1
Preparation for activating TSD21 safety system:
– Activate the “Automatic Car Positioning Sequence” by pressing the
“RESET INSPECTION” button on SMICHMI for more than 3 seconds when
controller is in normal mode.
– All registered car calls will be served and all landing calls will be cancelled.
– The car first travels to the landing floor where the controller is installed and
opens the doors, allowing the maintenance person to check that the car is
empty.
– Press “RESET INSPECTION” button again.
– The doors are closed and the car starts to travel down until the car roof is
at the floor level of the landing where the controller is located.
– Maintenance person can now open the shaft door with a triangular key (this
action activates the TSD21 safety system).
– Press JHC.
– Entering car roof.
– Activate the TSD21 lever.
– Extract/unfold the balustrade, if any
– Switch JREC to “Inspection”.
– Release JHC only if JREC has been switched to “Inspection”
– Press the top of car stop button (JHC)
– Switch JREC to “Normal”
– Exit the top of car
– Release the top of car stop switch (JHC) only after having exited the car
roof
– Close the shaft door giving access to the top of car
2 Preparation for entering shaft pit:
– Maintenance person goes to the lowest floor whose shaft door gives
access to the pit, then open the shaft door with a triangular key.
– Press JHSG1 on Pit Box close to the shaft door.
– Entering shaft pit, if necessary with the help of the pit ladder.
3 Activation:
– Switch JRESG to “Inspection”.
– If necessary, return the pit ladder to its designated location.
– Release JHSG1 on Pit Box only if JRESG has been switched to
“Inspection”.
4 Operation:
– Press and hold DRESG_U and DRESG_E to move the car upwards.
– Press and hold DRESG_D and DRESG_E to move the car downwards.
– Release DRESG_U or DRESG_D or DRESG_E to stop the car movement.
– Press JHSG on Pit Inspection Panel to stop the car movement.
5 Deactivation of pit inspection mode:
– Press JHSG1.
– Switch JRESG to “Normal”.
– Open the shaft door and leave the pit, if necessary with the help of the pit
ladder.
– If necessary, return the pit ladder to its designated location.
– Release JHSG1 only after leaving the shaft pit.
– Close the shaft door for pit access.
