CV-LS Dashboard
D20980.022 Rev C CV-LS User Manual Page 57
Control Name
Description
LED Temp
Temperature of the LED.
Normal Operational Range: 0 – 80C
Warning Range: 80 – 90C
Thermal Shutdown: 90C
LED Status
Green when temperature sensor is fully operational. Yellow when
temperature is still accurate, but sensor is degraded. Red when temperature
is no longer accurate.
Board Temp
Temperature of the LED.
Normal Operational Range: 0 – 65C
Warning Range: 65 – 80C
Thermal Shutdown: 80C
Ref Voltage
5V output voltage measurement.
Input Voltage
Measurement of the current input voltage. Unit will run on 18-28V.
Fan Speed
RPM of the unit fan. Range from 7 – 23K
Equalizer
Status of the equalizer when enabled.
Light Feedback
Current light output value. Value has no units and is not calibrated. Used
internally to stabilize output through equalizer functions.
Last Command
Shows the last interface that received input.
System Mode
Currently active unit mode.
User Mode
Last user selected mode.
Knob Mode
Last user selected knob mode.
System Date
When unit has internet access, time will be set from NTP servers.
Serial
Unit model and serial number.
Settings Write Count
Number of times the user has stored settings in the unit. Max value >40e6
Factory Write Count
Number of times the factory has written default settings. Max value >1.6e6
SPI Erase Count
Number of times the unit firmware has been written. Max value > 1e4
Error Log Count
Number of times a system exception has occurred. Max value > 25.6e6
