Product Specification
D20980.022 Rev C CV-LS User Manual Page 83
Product Specification
Environment
Operational Temperature
CV-LS: 0C to 45C.
Power Supply: -30C to 50C.
There are temperature sensors on the LED module and PCB. Readings are accessible through software
interfaces. Software controls will not allow the LED to be driven over its maximum operating
temperature and will automatically dim the LED to prevent damage.
Storage Temperature
CV-LS: -25C to 85C
Power Supply: -40C to 85C
Humidity
CV-LS: 5% to 95% Non-Condensing
Power Supply: 20% to 90% Non-Condensing
Electrical
Input
CV-LS: 18-28VDC / 5A Max
Power Supply: 85 – 264 VAC, 47 – 63 Hz, 120W
The CV-LS must have an Earth Ground connection for EMC Compliance.
Users must adhere to one of the following:
Use the included AC/DC power supply. Third prong must be connected to Earth Ground.
One of the GND pins in the Multiport Connector must be connected to Earth Ground.
Redundant Power Inputs
The CV-LS can be powered through either the Multiport terminal block or the DC Power Input. Both of
these inputs are isolated from the other through a load sharing circuit built into the CV-LS. This means
the user can supply power through both interfaces without damaging either supply, allowing for
redundant supply inputs.
