SCHOTTEL SV 1 - Page 81

en
1/
Piping Systems for Hydraulic, Lubrication and Similar SystemsSTD--Wa 07/3110 1099237 17
Piping Systems for Hydraulic, Lubrication
and Similar Systems
Table of Contents
1 Conduits 3...................................................................
General 3.....................................................................
Cold bending of pipes 3.........................................................
Cutting pipes to length 4........................................................
Hot bending of pipes 4..........................................................
Reducing adapters 5...........................................................
Reducing joints 5.............................................................
Reducing adapters directly inside the pipe 5.....................................
Fastening of conduits 6.........................................................
2HoseLines 7.................................................................
General 7.....................................................................
Placing of hose lines 7..........................................................
3 Threaded Joints 10.............................................................
General 10.....................................................................
Cutting ring joint to DIN 386110 10................................................
Preassembly 10...............................................................
Threaded joint with c utting ring and DSW--sealing 12................................
Threaded joint with s ealing cone and O--ring 12.....................................
Tightening related to turning angle 13..............................................
Tightening with torque wrench 13.................................................
4 Flange Joints 14...............................................................
General 14.....................................................................
5 Sealing and Securing Material 16................................................
General instructions for use 16....................................................
6 Final Mounting 17..............................................................
