Assembly
24
14.00 | JGP | Assembly and Operating Manual | en | 389157
Item Mounting
JGP
160 200 240 300
Side A
1 Mounting screw M8 M10 M12 M16
Max. depth of engagement
from locating surface [mm]
for variants IS/AS
20
20
20
20
25.5
23
31
31
2 Centering sleeve Ø12 Ø14 Ø16 Ø22
6 Fitting bore for centering
pin [mm]
Ø6
H7
– – Ø10
H7
Side B
4 Mounting screw M6 M8 M10 M12
Mounting screw according
to standard
DIN EN ISO 4762
2 Centering sleeve Ø12 Ø14 Ø16 Ø22
Side C
5 Mounting screw M8 M10 M12 M16
Mounting screw according
to standard
DIN EN ISO 4762
Max. strength class 8.8
3 Centering sleeve Ø12 Ø14 Ø16 Ø22
7 Fitting bore for centering
pin [mm]
Ø6
H7
Ø8
H7
– Ø10
H7
